Hiblow HP-Series Pond Aeration Kits
Looking for a dependable pond aeration system? Best Planet offers complete Hiblow HP-Series pond aeration kits designed for backyard ponds, koi ponds, and larger water features.
These professional-grade aeration systems combine reliable Hiblow air pumps with carefully matched aeration components, including weighted airline tubing and Matala diffusers. With eight pump models available, you can compare airflow, operating pressure, electrical consumption, and recommended pond capacity to find the right system for your pond.
Whether you're aerating a small garden pond or a large koi pond, Hiblow HP-Series aeration kits provide options for a variety of pond sizes and aeration requirements.
Benefits of subsurface aeration:
- Helps keep the water clear of algae and other organic matter
- Promotes healthy oxygen levels for fish growth and sustainability
- Helps evenly distribute oxygen and water temperature
- Creates a hole in the ice in the winter which allows toxic gases to release preventing fish kill
-
Please note these items will potentially ship in multiple boxes.
HiBlow HP-Series Air Pump Comparison
Compare HiBlow HP-Series air pumps to find the right model for your pond. Review pond capacity, operating depth, air output, power consumption and recommended Matala diffuser accessories. Scroll horizontally to see all columns.
| Model | Recommended Pond Size | Max Depth (ft) | Rated Air Flow at Loading Pressure | Max Continuous Operating Pressure | Power (Watts) | Noise (dBA @ 1m) | Weight (kg) | Included Hose Connector | Barb Fitting Size | Included Diffuser | Included Weighted Airline |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HP-20 | Up to 7,000 Gallons | 6 | 20 LPM @ 9.8 kPa OR 0.706 CFM @ 1.42 psi |
15 kPa / 2.1 psi | 17 | 32 | 3.2 | 90° L-Tube 5/8" ID |
5/8" OD | Matala MD-5W Weighted Diffuser | 3/8" x 30' Weighted Airline |
| HP-40 | Up to 16,000 Gallons | 10 | 40 LPM @ 12.8 kPa OR 1.41 CFM @ 1.86 psi |
20 kPa / 2.9 psi | 38 | 32 | 5.7 | 90° L-Tube 5/8" ID |
5/8" OD |
MD-7W Weighted Diffuser OR 2 MD-5W Diffusers with SC2-38 Manifold |
3/8" x 30' Weighted Airline |
| HP-60 | Up to 1/4 Acre | 10 | 60 LPM @ 14.7 kPa OR 2.12 CFM @ 2.13 psi |
25 kPa / 3.6 psi | 51 | 35 | 7 | 90° L-Tube 5/8" ID |
5/8" OD | 2 MD-7W Diffusers with SC2-38 Manifold OR MDB11 Diffuser Base |
3/8" x 30' Weighted Airline |
| HP-80 | Up to 1/2 Acre | 10 | 80 LPM @ 14.7 kPa OR 2.82 CFM @ 2.13 psi |
25 kPa / 3.6 psi | 71 | 36 | 7 | 90° L-Tube 5/8" ID |
5/8" OD | MDB11 Diffuser Base | 3/8" x 50' Weighted Airline |
| HP-100 | Up to 3/4 Acre | 10 | 100 LPM @ 17.7 kPa OR 3.53 CFM @ 2.57 psi |
230 kPa / 4.3 psi | 100 | 38 | 8.5 | 90° L-Tube 5/8" ID |
5/8" OD | MDB12 Diffuser Base | — |
| HP-120 | Up to 1 Acre | 10 | 120 LPM @ 17.7 kPa OR 4.24 CFM @ 2.57 psi |
30 kPa / 4.3 psi | 125 | 40 | 8.5 | 90° L-Tube 5/8" ID |
5/8" OD | MDB12 Diffuser Base | — |
| HP-150 | Up to 1.5 Acres | 10 | 150 LPM @ 20 kPa OR 5.30 CFM @ 2.9 psi |
30 kPa / 4.3 psi | 155 | 47 | 9 | 5/8"–1" ID Straight Hose | 1" OD | — | — |
| HP-200 | Up to 2 Acres | 10 | 200 LPM @ 20 kPa OR 7.06 CFM @ 2.9 psi |
30 kPa / 4.3 psi | 250 | 46 | 9 | 5/8"–1" ID Straight Hose | 1" OD | — | — |
On mobile devices, swipe left or right to view all specifications.
Pond size recommendations are guidelines. Actual aeration requirements depend on pond depth, shape, fish load, and other operating conditions. Accessory configurations are shown as supplied.
Find the Right Hiblow HP-Series Aeration Kit
Compare eight Hiblow air pump models and find the right aeration system for your pond.
Hiblow HP-20
Compact, lower-capacity aeration option for smaller ponds and water gardens.
Best for: Smaller ponds
Hiblow HP-40
A step up in airflow for ponds requiring additional aeration capacity.
Best for: Small to medium ponds
Hiblow HP-60
Higher airflow for larger pond installations and multiple diffuser locations.
Best for: Medium-sized ponds
Hiblow HP-80
A higher-capacity compressor option for larger pond aeration applications.
Best for: Larger ponds
Hiblow HP-100
Designed for pond installations requiring increased airflow capacity.
Best for: Large ponds
Hiblow HP-120
A higher-output option for larger pond systems with greater aeration demands.
Best for: Large pond systems
Hiblow HP-150
High-capacity aeration for installations requiring substantial airflow.
Best for: Very large ponds
Hiblow HP-200
The largest pump in this comparison, offering the highest rated airflow of the eight models.
Best for: Large-scale aeration
**PLEASE NOTE: Recommended Diffusers are a suggestion based on the Hiblow Air Pump specs. If you have questions, chat with us or send an email to carol@best-planet.com
Some Things to Consider
-
HIBLOW recommendations are general guidelines for selecting a pump.
-
For depths greater than 6′, you may want to consider bumping up to the next size pump to offset the loss of air from the increase in pressure.
-
If you have an odd or kidney shaped pond, it may be advisable to contact a pond distributor for guidance as you may need multiple diffusers to properly mix and aerate the whole pond.
-
If breeding specific types of fish, we would recommend consulting with an aquatic specialist before selecting a pump as certain breeds require different levels of oxygen.
Aeration System Recommendations for Best Results
- Keep the pump covered and, in the shade, and allow for enough air circulation around the pump.
- 1/2″ ID tubing/ weighted line is suggested for distances between 50′-100′ and 3/4″ ID beyond 100′.
- You may consider using a “Y” connection instead of a “T” connection when splitting the line for multiple diffusers to reduce backpressure.
- Use medium bubble diffusers to limit backpressure and increase air flow. Place each at the same depth or use ball valves to even out the air flow/ pressure.
Spec Sheets
